TLW-108-06-G-D

Conn Unshrouded Header HDR 16POS 2.54mm Solder ST Thru-Hole

Connector Header Through Hole 16 position 0.100" 2.54mm

得捷:
CONN HEADER VERT 16POS 2.54MM

艾睿:
Safety is an important concern when designing electronic devices. Samtec&s;s unshrouded TLW-108-06-G-D header connector helps protect your equipment from accidental shortages. This HDR connector&s;s 16 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a header type gender. It has a straight body orientation. Its pitch is 2.54 mm. This is a 2-row connector. This device has a maximum current rating of 5.2 A/contact. TLW-108-06-G-D is housed in black liquid crystal polymer. This connector has an operating temperature of -55 to 125 °C. This product is 20.32 mm long, 4.19 mm tall and 5.03 mm deep. It uses the solder termination method.

安富利:
Conn Unshrouded Header HDR 16 POS 2.54mm Solder ST Thru-Hole

Verical:
Conn Unshrouded Header HDR 16 POS 2.54mm Solder ST Top Entry Thru-Hole Bulk

Newark:
# SAMTEC  TLW-108-06-G-D  LOW PROFILE .025 SQ STRIPS
