HEADER, 2.54MM, SMT, R/A, 30POS; Series: TSM; Pitch Spacing: 2.54mm; No. of Rows: 2
针座 表面贴装，直角 30 位置 0.100"（2.54mm）
得捷:
CONN HEADER SMD R/A 30POS 2.54MM
艾睿:
Thanks to Samtec&s;s unshrouded TSM-115-01-S-DH header connector, you can reduce the possibility of accidentally shorting out any pins on your printed circuit. This HDR connector&s;s 30 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a maximum voltage rating of 475 VAC. It has a right angle body orientation. Its pitch is 2.54 mm. This is a 2-row connector. It has a header type gender. This device has a maximum current rating of 5.4 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. It uses the solder termination method. TSM-115-01-S-DH is housed in black liquid crystal polymer. This connector has an operating temperature of -55 to 125 °C. This product is 38.1 mm long, 6.1 mm tall and 16.25 mm deep.
安富利:
Conn Unshrouded Header HDR 30 POS 2.54mm Solder RA SMD Tube
Newark:
# SAMTEC TSM-115-01-S-DH Board-To-Board Connector, 2.54 mm, 30 Contacts, Header, TSM Series, Surface Mount, 2 Rows
