TSW-112-14-S-D

2.54mm 方针

Conn Unshrouded Header HDR 24 POS 2.54mm Solder ST Thru-Hole Bag

得捷:
CONN HEADER VERT 24POS 2.54MM

欧时:
HEADER TH 24POS 2 ROW

立创商城:
2.54mm 方针

艾睿:
Mount this unshrouded TSW-112-14-S-D header connector from Samtec on a jumper post on your PCB to support physical configuration options. This HDR connector&s;s 24 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 2.54 mm. This is a 2-row connector. It has a maximum voltage rating of 550 VAC. It has a straight body orientation. It has a header type gender. This device has a maximum current rating of 6.3 A/contact. It uses the solder termination method. TSW-112-14-S-D is housed in black polyester. This product is 30.48 mm long, 10.67 mm tall and 5.08 mm deep. This connector has an operating temperature of -55 to 125 °C.

安富利:
Conn Unshrouded Header HDR 24 POS 2.54mm Solder ST Thru-Hole

Newark:
# SAMTEC  TSW-112-14-S-D  .025 Sq. Terminal Strips

Online Components:
Conn Unshrouded Header HDR 24 POS 2.54mm Solder ST Thru-Hole Bag

Electro Sonic:
Conn Unshrouded Header HDR 24 POS 2.54mm Solder ST Thru-Hole Bag
