TSW-130-08-T-S-RA

2.54mm 方针

针座 通孔，直角 30 位置 0.100"（2.54mm）

得捷:
CONN HEADER R/A 30POS 2.54MM

立创商城:
2.54mm 方针

艾睿:
Samtec&s;s unshrouded TSW-130-08-T-S-RA header connector is a great way to reduce safety concerns in projects where there is a possibility of accidentally shorting electronic components. This HDR connector&s;s 30 contacts that are made out of phosphor bronze and plated with tin over nickel. It has a maximum voltage rating of 450 VAC. It has a right angle body orientation. It has a header type gender. Its pitch is 2.54 mm. This is a 1-row connector. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This connector has an operating temperature of -55 to 105 °C. It uses the solder termination method. This product is 76.2 mm long, 3.02 mm tall and 9.9 mm deep. TSW-130-08-T-S-RA is housed in black polyester.

安富利:
Conn Unshrouded Header HDR 30 POS 2.54mm Solder RA Thru-Hole

Newark:
# SAMTEC  TSW-130-08-T-S-RA  Board-To-Board Connector, 2.54 mm, 30 Contacts, Header, TSW Series, Through Hole, 1 Rows
