TSW-118-17-T-D

SAMTEC TSW-118-17-T-D Board-To-Board Connector, 2.54mm, 36Contacts, Header, TSW Series, Through Hole, 2Rows

针座 通孔 36 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 36POS 2.54MM

艾睿:
Use this unshrouded TSW-118-17-T-D header connector from Samtec where IDC ribbon cables are used. This HDR connector&s;s 36 contacts that are made out of phosphor bronze and plated with tin over nickel. It has a maximum voltage rating of 550 VAC. It has a header type gender. Its pitch is 2.54 mm. It has a straight body orientation. This is a 2-row connector. This device has a maximum current rating of 6.3 A/contact. This connector has an operating temperature of -55 to 105 °C. TSW-118-17-T-D is housed in black polyester. This product is 45.72 mm long, 18.28 mm tall and 5.08 mm deep. It uses the solder termination method.

Verical:
Conn Unshrouded Header HDR 36 POS 2.54mm Solder ST Top Entry Thru-Hole Bulk

Newark:
# SAMTEC  TSW-118-17-T-D  Board-To-Board Connector, 2.54 mm, 36 Contacts, Header, TSW Series, Through Hole, 2 Rows
