SAMTEC TSW-114-07-F-D Board-To-Board Connector, 2.54mm, 28Contacts, Header, TSW Series, Through Hole, 2Rows
针座 通孔 28 位置 0.100"（2.54mm）
欧时:
Classic PCB HDR Strips 0.100"
得捷:
CONN HEADER VERT 28POS 2.54MM
艾睿:
Support physical configuration options for jumper posts by mounting this unshrouded TSW-114-07-F-D header connector from Samtec. This HDR connector&s;s 28 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a header type gender. Its pitch is 2.54 mm. This is a 2-row connector. It has a straight body orientation. It has a maximum voltage rating of 550 VAC. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This connector has an operating temperature of -55 to 125 °C. This product is 35.56 mm long, 8.38 mm tall and 5.08 mm deep. TSW-114-07-F-D is housed in black polyester. It uses the solder termination method.
Newark:
# SAMTEC TSW-114-07-F-D Board-To-Board Connector, 2.54 mm, 28 Contacts, Header, TSW Series, Through Hole, 2 Rows
