TSW-103-12-F-S-RA

SAMTEC TSW-103-12F-S-RA Board-To-Board Connector, 2.54mm, 3Contacts, Header, TSW Series, Through Hole, 1Rows

针座 通孔，直角 3 位置 0.100"（2.54mm）

得捷:
CONN HEADER R/A 3POS 2.54MM

艾睿:
Use this unshrouded TSW-103-12-F-S-RA header connector from Samtec where IDC ribbon cables are used. This HDR connector&s;s 3 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 1-row connector. It has a maximum voltage rating of 450 VAC. It has a right angle body orientation. It has a header type gender. Its pitch is 2.54 mm. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This product is 7.62 mm long, 3.02 mm tall and 9.9 mm deep. It uses the solder termination method. TSW-103-12-F-S-RA is housed in black polyester. This connector has an operating temperature of -55 to 125 °C.

Newark:
# SAMTEC  TSW-103-12-F-S-RA  Board-To-Board Connector, 2.54 mm, 3 Contacts, Header, TSW Series, Through Hole, 1 Rows
