TST-107-04-G-D-RA

SAMTEC TST-107-04-G-D-RA Wire-To-Board Connector, 2.54mm, 14Contacts, Header, TST Series, Through Hole, 2Rows

Connector Header Through Hole, Right Angle 14 position 0.100" 2.54mm

得捷:
CONN HEADER R/A 14POS 2.54MM

艾睿:
Mount this shrouded TST-107-04-G-D-RA header connector from Samtec on a jumper post on your PCB to support physical configuration options. This HDR connector&s;s 14 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a right angle body orientation. This is a 2-row connector. It has a header type gender. Its pitch is 2.54 mm. This device has a maximum current rating of 3.4 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This connector has an operating temperature of -55 to 125 °C. This product is 25.4 mm long, 9.27 mm tall and 12.32 mm deep. TST-107-04-G-D-RA is housed in black polyester. It uses the solder termination method.

安富利:
Conn Shrouded Header HDR 14 POS 2.54mm Solder RA Thru-Hole Tube

Newark:
# SAMTEC  TST-107-04-G-D-RA  Wire-To-Board Connector, 2.54 mm, 14 Contacts, Header, TST Series, Through Hole, 2 Rows
