TMS-115-02-G-S

SAMTEC TMS-115-02-G-S Board-To-Board Connector, 1.27mm, 15Contacts, Header, TMS Series, Through Hole, 1Rows

针座 通孔 15 位置 0.050"（1.27mm）

得捷:
CONN HEADER 15POS .050" T/H GOLD

欧时:
.050" x .100" Micro Terminal Strip

艾睿:
Are you looking for a solution to support physical configuration options on your PCB? Then mount this unshrouded TMS-115-02-G-S header connector from Samtec on your PCB today! This HDR connector&s;s 15 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. It has a header type gender. This is a 1-row connector. Its pitch is 1.27 mm. This device has a maximum current rating of 5 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. It uses the solder termination method. This product is 19.05 mm long, 5.08 mm tall and 2.48 mm deep. TMS-115-02-G-S is housed in black liquid crystal polymer. This connector has an operating temperature of -55 to 125 °C.

安富利:
Conn Unshrouded Header HDR 15 POS 1.27mm Solder ST Thru-Hole Tube

Newark:
# SAMTEC  TMS-115-02-G-S  Board-To-Board Connector, 1.27 mm, 15 Contacts, Header, TMS Series, Through Hole, 1 Rows
