TSM-106-04-T-SV-TR

2.54mm 方针

针座 表面贴装型 6 位置 0.100"（2.54mm）

得捷:
CONN HEADER SMD 6POS 2.54MM

立创商城:
2.54mm 方针

艾睿:
Are you looking for a solution to support physical configuration options on your PCB? Then mount this unshrouded TSM-106-04-T-SV-TR header connector from Samtec on your PCB today! This HDR connector&s;s 6 contacts that are made out of phosphor bronze and plated with tin over nickel. This is a 1-row connector. Its pitch is 2.54 mm. It has a header type gender. It has a maximum voltage rating of 475 VAC. It has a straight body orientation. This device has a maximum current rating of 5.4 A/contact. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This connector has an operating temperature of -55 to 105 °C. TSM-106-04-T-SV-TR is housed in black liquid crystal polymer. This product is 15.24 mm long, 6.86 mm tall and 4.82 mm deep. It uses the solder termination method.

Verical:
Conn Unshrouded Header HDR 6 POS 2.54mm Solder ST Top Entry SMD T/R

Newark:
# SAMTEC  TSM-106-04-T-SV-TR  Board-To-Board Connector, 2.54 mm, 6 Contacts, Header, TSM Series, Surface Mount, 1 Rows
