TSW-110-07-F-S

SAMTEC TSW-110-07-F-S Board-To-Board Connector, 2.54mm, 10Contacts, Header, TSW Series, Through Hole, 1Rows

针座 通孔 10 位置 0.100"（2.54mm）

欧时:
.100" Terminal Strip

得捷:
CONN HEADER VERT 10POS 2.54MM

艾睿:
Are you looking for a solution to support physical configuration options on your PCB? Then mount this unshrouded TSW-110-07-F-S header connector from Samtec on your PCB today! This HDR connector&s;s 10 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 2.54 mm. It has a maximum voltage rating of 550 VAC. It has a straight body orientation. This is a 1-row connector. It has a header type gender. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This connector has an operating temperature of -55 to 125 °C. This product is 25.4 mm long, 8.38 mm tall and 2.54 mm deep. TSW-110-07-F-S is housed in black polyester. It uses the solder termination method.

安富利:
Conn Unshrouded Header HDR 10 POS 2.54mm Solder ST Thru-Hole

Newark:
# SAMTEC  TSW-110-07-F-S  Board-To-Board Connector, 2.54 mm, 10 Contacts, Header, TSW Series, Through Hole, 1 Rows
