Conn Unshrouded Header HDR 32POS 2.54mm Solder RA Thru-Hole
针座 通孔,直角 32 位置 0.100"(2.54mm)
得捷:
CONN HEADER R/A 32POS 2.54MM
艾睿:
Thanks to Samtec&s;s unshrouded TSW-116-08-S-D-RA header connector, you can reduce the possibility of accidentally shorting out any pins on your printed circuit. This HDR connector&s;s 32 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a header type gender. This is a 2-row connector. Its pitch is 2.54 mm. It has a maximum voltage rating of 450 VAC. It has a right angle body orientation. This device has a maximum current rating of 6.3 A/contact. TSW-116-08-S-D-RA is housed in black polyester. It uses the solder termination method. This product is 40.64 mm long, 5.56 mm tall and 12.44 mm deep. This connector has an operating temperature of -55 to 125 °C.
Newark:
# SAMTEC TSW-116-08-S-D-RA .025 Sq. Terminal Strips
触点数 32
极性 Male
触点电镀 Gold
排数 2
针脚数 32
额定电流Max 6.3A/触头
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压Max 450 VAC
安装方式 Through Hole
引脚间距 2.54 mm
长度 40.6 mm
宽度 2.54 mm
高度 5.56 mm
引脚间距 2.54 mm
外壳颜色 Black
颜色 Black
触点材质 Phosphor Bronze
工作温度 -55℃ ~ 125℃
外壳材质 Plastic
产品生命周期 Active
包装方式 Bulk
制造应用 -
RoHS标准 RoHS Compliant
含铅标准 Lead Free
