MACROMATIC CONTROLS TR-53122-08 Time Delay Relay, Repeat Cycle Off First, TR-5 Series, DPDT, 10A, Socket, 240VAC, Quick Connect
Macromatic’s TR-5 Series Time Delay Relays provide onboard & remote adjustable or fixed time delays. They are available in many functions.
* Repeat Cycle Off First
* 0.6-60 Sec
* Used industry-standard 8 pin octal socket
* Pilot Duty Rating
Specifications
* DPDT 10A @ 240VAC/DC
* Temperature: –28°C to 65°C
* Dimensions: 3.5" D × 1.7" W × 2.4" H
Description of Function:
Upon application of input voltage, the time delay t1 begins. At the end of the time delay t1, the output is energized and remains in that condition for the time delay t2. At the end of this time delay, the output is de-energized and the sequence repeats until input voltage is removed.
