TPSMA6L9.0A

LITTELFUSE TPSMA6L9.0A TVS Diode, TPSMA6L Series, Unidirectional, 9V, 15.4V, DO-221AC, 2Pins

15.4V 夹子 39A Ipp TVS - 表面贴装型 DO-221AC

立创商城:
Vrwm:9V 600W

得捷:
TVS DIODE 9VWM 15.4VC DO221AC

艾睿:
Take the extra step in your circuitry by implementing surge protection with this TPSMA6L9.0A TVS diode from Littelfuse. Its test current is 1 mA. This device&s;s maximum clamping voltage is 15.4 V and minimum breakdown voltage is 10 V. Its maximum leakage current is 10 μA. Its peak pulse power dissipation is 600 W. This TVS diode has a minimum operating temperature of -65 °C and a maximum of 150 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery.

Chip1Stop:
Diode TVS Single Uni-Dir 9V 600W Automotive 2-Pin DO-221AC T/R

TME:
Diode: transil; 600W; 10.6V; 39A; unidirectional; ±5%; DO221AC

Newark:
# LITTELFUSE  TPSMA6L9.0A  TVS Diode, TPSMA6L Series, Unidirectional, 9 V, 15.4 V, DO-221AC, 2 Pins
