Electromechanical Relay 48VDC 8.79KΩ 15A SPDT 30mm 10mm 15mm THT General Purpose Relay
Electromechanical Relay 48VDC 8.79KOhm 15A SPDT 30mm 10mm 15mm THT General Purpose Relay
贸泽:
General Purpose Relays SPDT 10A 48VDC MINIATURE PWR RELAY
艾睿:
Power Relay
Allied Electronics:
T75S5D112-48=V23061-B1009-X10, 4-1393223-1
Chip1Stop:
Electromechanical Relay 48VDC 8.79KOhm 15A SPDT 30mm 10mm 15mm THT General Purpose Relay
Verical:
Electromechanical Relay 48VDC 8.79KOhm 15A SPDT 30mm 10mm 15mm THT General Purpose Relay
MASTER:
Power Relay 48VDC 8A SPDT30x10x15mm THT
Online Components:
Electromechanical Relay 48VDC 8.79KOhm 15A SPDT 30mm 10mm 15mm THT General Purpose Relay
Electro Sonic:
Power Relay 48VDC 8A SPDT30x10x15mm THT
额定电压AC 400 V
功耗 230 mW
触点额定电流 15 A
线圈电压 48 V
线圈电流 5.5 mA
线圈电阻 8.79 KΩ
额定电流Max 15 A
线圈电压DC 48 V
额定功率Max 2 KVA
工作温度Max 85 ℃
工作温度Min -40 ℃
额定电压AC Max 400 V
安装方式 Through Hole
引脚数 5
长度 30 mm
宽度 10 mm
高度 15 mm
触点材质 Silver Cadmium Oxide
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8536490080
