低信号继电器 - PCB 2A 4.5VDC 150MW PCB RELAY LATCHING
Electromechanical Relay 4.5VDC 135Ohm 2A DPDT 15x7.4x8.2mm THT General Purpose Relay
得捷:
RELAY GEN PURPOSE DPDT 2A 4.5VDC
贸泽:
低信号继电器 - PCB 2A 4.5VDC 150MW PCB RELAY LATCHING
Allied Electronics:
RELAY GEN PURPOSE DPDT 2A 4.5V
Chip1Stop:
Electromechanical Relay DPDT 2A 4.5VDC 135Ohm Through Hole
Verical:
Electromechanical Relay 4.5VDC 135Ohm 2A DPDT 15x7.4x8.2mm THT General Purpose Relay
MASTER:
Electromechanical Relay 4.5VDC 135Ohm 2A DPDT 15x7.4x8.2mm THT General Purpose Relay
Online Components:
Electromechanical Relay 4.5VDC 135Ohm 2A DPDT 15x7.4x8.2mm THT General Purpose Relay
Electro Sonic:
Electromechanical Relay 4.5VDC 135Ohm 2A DPDT 15x7.4x8.2mm THT General Purpose Relay
功耗 150 mW
触点额定电流 2 A
线圈电压 4.5 VDC
线圈电流 33.3 mA
线圈电阻 135 Ω
额定电流Max 2 A
线圈电压DC 4.5 V
线圈功率 150 mW
额定功率Max 60 W
开关电流Max 2 A
额定电压DC Max 220 V
安装方式 Through Hole
引脚数 8
封装 DIP
长度 15 mm
宽度 7.4 mm
高度 8.2 mm
封装 DIP
触点材质 Silver, Gold
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8536490050
