TMM-107-01-G-S

Conn Unshrouded Header HDR 7POS 2mm Solder ST Thru-Hole

Connector Header Through Hole 7 position 0.079" 2.00mm

得捷:
CONN HEADER VERT 7POS 2MM

艾睿:
Make strong and binding connections on your circuit boards by adopting this unshrouded TMM-107-01-G-S connector from Samtec. This HDR connector&s;s 7 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a maximum voltage rating of 500 VAC. It has a header type gender. It has a straight body orientation. This is a 1-row connector. Its pitch is 2 mm. This device has a maximum current rating of 5.5 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. TMM-107-01-G-S is housed in black liquid crystal polymer. This connector has an operating temperature of -55 to 125 °C. This product is 14 mm long, 4.7 mm tall and 1.97 mm deep. It uses the solder termination method.

Newark:
# SAMTEC  TMM-107-01-G-S  2mm TERMINAL STRIP
