TLW-114-06-T-S

Conn Unshrouded Header HDR 14POS 2.54mm Solder ST Thru-Hole

针座 通孔 14 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 14POS 2.54MM

艾睿:
Use this unshrouded TLW-114-06-T-S connector from Samtec when board-to-board interconnects is required. This HDR connector&s;s 14 contacts that are made out of phosphor bronze and plated with tin over nickel. This is a 1-row connector. Its pitch is 2.54 mm. It has a header type gender. It has a straight body orientation. This device has a maximum current rating of 5.2 A/contact. This product is 35.56 mm long, 4.19 mm tall and 2.48 mm deep. TLW-114-06-T-S is housed in black liquid crystal polymer. This connector has an operating temperature of -55 to 105 °C. It uses the solder termination method.

安富利:
Conn Unshrouded Header HDR 14 POS 2.54mm Solder ST Thru-Hole

Newark:
# SAMTEC  TLW-114-06-T-S  LOW PROFILE .025 SQ STRIPS
