TMM 60115

TMM 60115图片1
TMM 60115图片2
TMM 60115图片3
TMM 60115图片4
TMM 60115概述

TRACOPOWER 60W 1输出 嵌入式开关模式电源(SMPS), 15V dc, 4000mA

**60W, PCB/Chassis Mount, Encapsulated, Switch Mode, Medical, AC-DC Power Supply, TMM 60 Series**

The Tracopower TMM series of ultra compact AC/DC power supplies come in a fully encapsulated plastic case. These power supplies feature the latest medical safety approvals 2 x MOPP and extended operating temperature range from -40°C to +80°C making them suitable for worldwide markets. The TMM series AC/DC modules offer an interesting solution for many space critical applications in commercial, medical and industrial electronic equipment and comply with the latest European ErP directive.

TMM 60115中文资料参数规格
技术参数

额定功率 60 W

输出接口数 1

输出电压 15 VDC

输出电流 4 A

输出电流Max 4 A

输入电压 85VAC ~ 264VAC

封装参数

安装方式 Through Hole

封装 DIP-6

外形尺寸

长度 112 mm

宽度 67.8 mm

封装 DIP-6

物理参数

工作温度 -40℃ ~ 75℃

其他

产品生命周期 Active

包装方式 Tube

制造应用 工业,ITE(商用),医疗

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

数据手册

在线购买TMM 60115
型号: TMM 60115
制造商: Traco Electronic
描述:TRACOPOWER 60W 1输出 嵌入式开关模式电源(SMPS), 15V dc, 4000mA
