TL783CKC

HIGH-电压可调稳压器 HIGH-VOLTAGE ADJUSTABLE REGULATOR

description

The TL783 is an adjustable three-terminal high-voltage regulator with an output range of 1.25 V to 125 V and a DMOS output transistor capable of sourcing more than 700 mA. It is designed for use in high-voltage applications where standard bipolar regulators cannot be used. Excellent performance specifications, superior to those of most bipolar regulators, are achieved through circuit design and advanced layout techniques.

Output Adjustable From 1.25 V to 125 V When Used With an External Resistor Divider

700-mA Output Current

Full Short-Circuit, Safe-Operating-Area, and

Thermal-Shutdown Protection

0.001%/V Typical Input Voltage Regulation

0.15% Typical Output Voltage Regulation

76-dB Typical Ripple Rejection

Standard TO-220AB Package
