高速，低噪声，全差分I / O放大器 HIGH-SPEED, LOW-NOISE, FULLY-DIFFERENTIAL I/O AMPLIFIERS
DESCRIPON
The THS413x is one in a family of fully-differential input/differential output devices fabricated using Texas Instruments" state-of-the-art BiComI complementary bipolar process. The THS413x is made of a true fully-differential signal path from input to output. This design leads to an excellent common-mode noise rejection and improved total harmonic distortion.
FEATURES
• High Performance
– 150 MHz, –3 dB Bandwidth VCC= ±15 V
– 51 V/µs Slew Rate
– –100 dB Third Harmonic Distortion at 250 kHz
• Low Noise
– 1.3 nV/√Hz Input-Referred Noise
• Differential-Input/Differential-Output
– Balanced Outputs Reject Common-Mode Noise
– Reduced Second-Harmonic Distortion Due to Differential Output
• Wide Power-Supply Range
– VCC= 5 V Single Supply to ±15 V Dual Supply
• ICCSD = 860 µA in Shutdown Mode THS4130
APPLICATIONS
• Single-Ended To Differential Conversion
• Differential ADC Driver
• Differential Antialiasing
• Differential Transmitter And Receiver
• Output Level Shifter
