TL082BID

通用J- FET双运算放大器 GENERAL PURPOSE J-FET DUAL OPERATIONAL AMPLIFIERS

Description

The TL082, TL082A and TL082B are high speed JFET input dual operational amplifiers incorporating well matched, high voltage JFET and bipolar transistors in a monolithic integrated circuit.

The devices feature high slew rates, low input bias and offset current, and low offset voltage temperature coefficient.

Features

■ Wide common-mode up to VCC+ and differential voltage range

■ Low input bias and offset current

■ Output short-circuit protection

■ High input impedance JFET input stage

■ Internal frequency compensation

■ Latch up free operation

■ High slew rate: 16 V/µs typical
