高英法fi效率线性稳压器 High Efficiency Linear Regulator
线性稳压器控制器 IC 正固定式和负固定式 输出 20-PLCC(9x9)
得捷:
IC LNR REG CTRLR 2OUT 20PLCC
贸泽:
低压差电压控制器 Hi Efficiency
艾睿:
Made with greater design simplicity, this regulator UC2834Q controller from Texas Instruments is the perfect DC voltage regulator. With an adjustable output that has a voltage of 1.5Min V, this is power management at its best. It operates in Linear mode. This MOSFET controller has an input voltage of 40Max V. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This MOSFET controller has a minimum operating temperature of -40 °C and a maximum of 85 °C.
安富利:
LDO Cntrlr REG 1.5V 20-Pin PLCC Tube
Chip1Stop:
LDO Controller High Efficiency Linear Regulator LDO Cntrlr REG 1.5V 20-Pin PLCC Tube
Verical:
Standard Regulator Pos 1.5V 5A 20-Pin PLCC Tube
输出接口数 2
输出电压 1.5 V
输出电流 5000 mA
供电电流 5.5 mA
耗散功率 2 W
静态电流 5.50 mA
跌落电压 500 mV
输入电压Max 36 V
输入电压Min 5 V
输出电流Max 350 mA
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 2000 mW
输入电压 5V ~ 35V
安装方式 Surface Mount
引脚数 20
封装 PLCC-20
封装 PLCC-20
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
UC2834Q TI 德州仪器 | 当前型号 | 当前型号 |
UC2834QTR 德州仪器 | 类似代替 | UC2834Q和UC2834QTR的区别 |
UC3834QTR 德州仪器 | 类似代替 | UC2834Q和UC3834QTR的区别 |
