NKK SWITCHES UB15KKW015F-FF 按钮开关, 发光, SPDT, 0.1A, 28V, 绿色
Series UB low profile pushbuttons feature integral LED illumination, a choice of square or rectangular shapes, a choice of PCB or panel snap-in mounts and snap-acting contacts in momentary or maintained actions. Optional switch guards can prevent accidental operation. Optional UL recognized and CSA certified marks on switch may be ordered. Contact your Allied sales representative for details.
贸泽:
按钮开关 SPDT ON-ON GREEN
e络盟:
按钮开关, 发光, SPDT, 0.1A, 28V, 绿色
艾睿:
Ideal for quick switching situations this UB15KKW015F-FF push button switch manufactured from NKK Switches is a must. This device has a maximum current rating of 5 A @ 250VAC 30VDC. It has a SPDT configuration. This push switch has a minimum operating temperature of -25 °C and a maximum of 50 °C. The UB15KKW015F-FF push switch has a solder lug termination style. The maximum AC voltage rating is 250 VAC and the maximum DC voltage rating is 30 VDC. This product is 17.8 mm long, 17.5 mm tall and 17.8 mm deep.
Allied Electronics:
SWITCH; PUSHBUTTON; LIGHTED; LOW-PROFILE; SPDT; SNAP-IN; ON-ON; GREEN LED
Chip1Stop:
Switch Push Button ON ON SPDT Square Button 5A 250VAC 30VDC Momentary Contact Solder Lug Panel Mount
Verical:
Switch Push Button ON ON SPDT Square Button 5A 250VAC 30VDC Momentary Contact Solder Lug Panel Mount
Newark:
# NKK SWITCHES UB15KKW015F-FF Illuminated Pushbutton Switch, SPDT, On-On, 5 A, 250 V, Green
Powell:
LOW PROFILE PUSHBUTTON/ILLUMINATED/PC AND SOLDER
触点电镀 Gold, Copper Alloy
额定电压DC 30 V
接触器类型 Button
额定电压AC 125 V
额定电流 5 A
排数 1
方向 Vertical
触点类型 SPDT
针脚数 2
触点额定电流 5.00 A
额定电流Max 5A @250VAC, 30VDC
工作温度Max 50 ℃
工作温度Min -25 ℃
额定电压 125 VAC
接触电阻Max 50 mΩ
安装方式 Lug, Snap-In
长度 17.8 mm
宽度 17.8 mm
高度 17.5 mm
触点材质 Silver Alloy
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
