UWX1E4R7MCL2GB

NICHICON  UWX1E4R7MCL2GB  铝电解电容, 4.7uF 25V SMD

WX 系列

WX 铝电解器系列是 5.5mmL 芯片类型

设计用于表面安装到高密度 PC 板上

适用于自动安装机器，用输送带送料

85°C 时加载寿命为 2000 小时

符合 RoHS 指令 2011/65/EU

得捷:
CAP ALUM 4.7UF 20% 25V SMD

欧时:
Nichicon 铝电解电容器 WX 系列, 25V dc, 4.7μF 表面安装器件, UWX1E4R7MCL2GB

e络盟:
铝电解电容, 4.7uF 25V SMD

艾睿:
Manufactured from Nichicon, this electrolytic UWX1E4R7MCL2GB aluminum capacitor is made from aluminum foil anode and is ideal for filtering out low frequencies. It can withstand a voltage of 25 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 85 °C. It has a tolerance of 20%. Its leakage current is 3@2Min μA. Its capacitance value is 4.7uF. This product is 5.4 mm tall with a diameter of 3 mm.

Allied Electronics:
4.7uF 25 V Aluminium Electrolytic Capacitor; WX Series 2000h 3 Dia. x 5.5mm

TME:
Capacitor: electrolytic; SMD; 4.7uF; 25VDC; Ø3x5.4mm; ±20%; 2000h

Verical:
Cap Aluminum Lytic 4.7uF 25V 20% 3 X 5.4mm SMD 12mA 2000h 85C Automotive T/R

Newark:
# NICHICON  UWX1E4R7MCL2GB  SMD Aluminum Electrolytic Capacitor, Radial Can - SMD, 4.7 µF, 25 V, WX Series
