UB15SKG035C-CJ

UB15SKG035C-CJ图片1
UB15SKG035C-CJ图片2
UB15SKG035C-CJ图片3
UB15SKG035C-CJ图片4
UB15SKG035C-CJ图片5
UB15SKG035C-CJ概述

Switch Push Button ON ON SPDT Square Button 0.1A 28VAC 28VDC 0.4VA Momentary Contact PC Pins Thru-Hole

is manufactured by Switches and is categorized in the Pushbutton Switches category. UB15SKG035C-CJ is described as SWITCH PUSH SPDT 0.4VA 28V. Perfect Parts is a supplier of Switches and other Electromechanicals.


得捷:
SWITCH PUSH SPDT 0.4VA 28V


立创商城:
UB15SKG035C-CJ


艾睿:
Switch Push Button ON ON SPDT Square Button 0.1A 28VAC 28VDC 0.4VA Momentary Contact PC Pins Thru-Hole


Chip1Stop:
Switch Push Button ON ON SPDT Square Button 0.1A 28VAC 28VDC 0.4VA Momentary Contact PC Pins Thru-Hole


Powell:
LOW PROFILE PUSHBUTTON/ILLUMINATED/PC AND SOLDER


UB15SKG035C-CJ中文资料参数规格
技术参数

额定电压DC 28 V

接触器类型 Button

额定电压AC 28 V

排数 1

方向 Vertical

触点类型 SPDT

额定电流Max 0.1A @28VAC, 28VDC

工作温度Max 50 ℃

工作温度Min -25 ℃

接触电阻Max 100 mΩ

封装参数

安装方式 Through Hole

封装 -

外形尺寸

长度 15.24 mm

宽度 15.24 mm

高度 12.5 mm

封装 -

物理参数

工作温度 -25℃ ~ 50℃

其他

产品生命周期 Active

包装方式 Bulk

符合标准

RoHS标准 RoHS Compliant

含铅标准 Contains Lead

数据手册

在线购买UB15SKG035C-CJ
型号: UB15SKG035C-CJ
制造商: NKK 日本长野
描述:Switch Push Button ON ON SPDT Square Button 0.1A 28VAC 28VDC 0.4VA Momentary Contact PC Pins Thru-Hole
