UM9301

PIN二极管 PIN DIODE

DESCRIPTION

The PIN Diode utilizes special overall chip geometry with an extremely thick intrinsic “I” region, to offer unique capabilities in both RF switch and attenuator applications. Volume production also makes the diode an economical choice suitable for many commercial low power equipments. The UM9301 has been designed for use

in bridged TEE attenuator circuits commonly utilized for gain and slope control in CATV amplifiers.

KEY FEATURES

Specified low distortion

Low distortion properties at low reverse bias

Resistance specified at 3 current points

High reliability fused-in-glass construction

APPLICATIONS/BENEFIT

Little or no Bias required.

Operates as low as 2MHZ.

Available in leaded or surface mount packages.
