1MHz,低功耗BiCMOS电流模式PWM
升压,反激,正激转换器 稳压器 正 输出 升压,升压/降压 - DC DC 切换控制器 IC 8-SOIC
立创商城:
UCC2803DTR
得捷:
IC REG CTRLR MULT TOPOLOGY 8SOIC
德州仪器TI:
12V, 1A low power BICMOS 1MHz current mode PWM with 4.1V/3.6V UVLO and 100% duty cycle, -40C to 1
艾睿:
Never worry about a stable current not being supplied by using this UCC2803DTR current controller by Texas Instruments. This current mode controller supports boost|flyback|forward topology. Its single PWM output produces a current of 1000Max mA. Its switching regulator has a frequency of 1000 kHz. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This current mode controller&s;s maximum duty cycle is 100 %. This device has a maximum of 12 V. This current mode controller has an operating temperature range of -40 °C to 85 °C.
安富利:
Current Mode PWM Controller 1A 8-Pin SOIC T/R
Chip1Stop:
Current Mode PWM Controller 1A 8-Pin SOIC T/R
Verical:
Current Mode PWM Controller 5V 1000kHz Automotive 8-Pin SOIC T/R
力源芯城:
1MHz,低功耗BiCMOS电流模式PWM
Win Source:
Boost, Flyback, Forward Converter Regulator Positive Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 8-SOIC
频率 1.00 MHz
电源电压DC 10.0V max
输出接口数 1
输出电压 5 V
输出电流 ≤1000 mA
调节输出数 1
上升时间 41 ns
开关频率 31 kHz
拓扑结构 Boost, Flyback, Forward
占空比 100 %
最大占空比 99 %
下降时间 44 ns
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 3.6V ~ 12V
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
高度 1.5 mm
封装 SOIC-8
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
UCC2803DTR TI 德州仪器 | 当前型号 | 当前型号 |
UCC2803DG4 德州仪器 | 类似代替 | UCC2803DTR和UCC2803DG4的区别 |
UCC2803D 德州仪器 | 功能相似 | UCC2803DTR和UCC2803D的区别 |
UCC2803DTRG4 德州仪器 | 功能相似 | UCC2803DTR和UCC2803DTRG4的区别 |
