CD 系列低阻抗### 表面安装 105°C 系列
铝电解器
得捷:
CAP ALUM 10UF 20% 35V SMD
立创商城:
10uF ±20% 35V
欧时:
Nichicon 铝电解电容器 CD 系列 35V dc 10μF 表面安装器件 UCD1V100MCL1GS, ±20%容差, 最高+105°C
艾睿:
Manufactured from Nichicon, this electrolytic UCD1V100MCL1GS aluminum capacitor is made from aluminum foil anode and is ideal for filtering out low frequencies. It can withstand a voltage of 35 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. Its leakage current is 3.5@2Min μA. This product is 5.8 mm tall with a diameter of 5 mm. It has a tolerance of 20%. Its capacitance value is 10uF.
Allied Electronics:
10uF 35 V dc Aluminium Electrolytic Capacitor, CD Series 2000h 5 Dia. x 5.8mm
安富利:
Cap Aluminum 10uF 35V 20% 5 X 5.8mm SMD 160mA 2000 hr 105°C T/R
富昌:
CD Series 35 V 10 µF ±20 % SMT Can Aluminum Electrolytic Capacitor
TME:
Capacitor: electrolytic; low impedance; SMD; 10uF; 35VDC; Ø5x5.8mm
Verical:
Cap Aluminum Lytic 10uF 35V 20% 5 X 5.8mm SMD 160mA 2000h 105C Automotive T/R
额定电压DC 35 V
工作电压 35 VDC
电容 10 µF
等效串联电阻ESR 0.7 Ω
容差 ±20 %
产品系列 UCD
纹波电流 160 mA
纹波电流高频 80mA @120Hz
纹波电流低频 160mA @100kHz
工作温度Max 105 ℃
工作温度Min -55 ℃
额定电压 35 VDC
安装方式 Surface Mount
封装 SMD
长度 5.8 mm
高度 5.8 mm
直径 Φ5mm
封装 SMD
工作温度 -55℃ ~ 105℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 1000
寿命(小时) 2000 h
制造应用 通用, 汽车级
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
UCD1V100MCL1GS Nichicon 尼吉康 | 当前型号 | 当前型号 |
UWD1V100MCL1GS 尼吉康 | 类似代替 | UCD1V100MCL1GS和UWD1V100MCL1GS的区别 |
UUD1V100MCL1GS 尼吉康 | 功能相似 | UCD1V100MCL1GS和UUD1V100MCL1GS的区别 |
EEE-FC1V100AR 松下 | 功能相似 | UCD1V100MCL1GS和EEE-FC1V100AR的区别 |
