具有 4.1V/3.6V UVLO 和 50% 占空比的汽车类经济型单端 1MHz 电流模式 PWM 控制器 8-SOIC -40 to 125
Generate and regulate a stable current with this current controller by Texas Instruments. Its single PWM output produces a current of 1000 mA. This current mode controller supports boost|flyback|forward topology. Its switching regulator has a frequency of 1000 kHz. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This device has a maximum of 12 V. This current mode controller"s maximum duty cycle is 50 %. This current mode controller has a minimum operating temperature of -40 °C and a maximum of 125 °C.
频率 1.00 MHz
输出接口数 1
输入电压DC 48.0 V
输出电压 400 mV
输出电流 1000 mA
供电电流 1.2 mA
调节输出数 1
上升时间 41 ns
开关频率 1000 kHz
拓扑结构 Boost, Flyback, Forward
占空比 50 %
最大占空比 50 %
下降时间 44 ns
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 3.6V ~ 10V
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
封装 SOIC-8
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
UCC2813QDR-5Q1 TI 德州仪器 | 当前型号 | 当前型号 |
UCC2813QDR-2Q1 德州仪器 | 完全替代 | UCC2813QDR-5Q1和UCC2813QDR-2Q1的区别 |
UCC2813QDR-0Q1 德州仪器 | 完全替代 | UCC2813QDR-5Q1和UCC2813QDR-0Q1的区别 |
