UUL0J101MCL1GS

100uF ±20% 6.3V Φ6.3mm 5.8mm

铝电解器 径向，Can - SMD - 105°C 时为 5000 小时

得捷:
CAP ALUM 100UF 20% 6.3V SMD

艾睿:
Using this electrolytic UUL0J101MCL1GS aluminum capacitor from Nichicon in your electronic circuit you&s;ll be able to generate high heat for a given current level due to its relatively high equivalent series resistance. It can withstand a voltage of 6.3 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. Its leakage current is 3@2Min μA. This product is 5.8 mm tall with a diameter of 6.3 mm. Its capacitance value is 100uF. It has a tolerance of 20%.

安富利:
Cap Aluminum 100uF 6.3V 20% 6.3 X 5.8mm SMD 60mA 5000 hr 105°C T/R

Chip1Stop:
Cap Aluminum Lytic 100uF 6.3V 20% 6.3 X 5.8mm SMD 60mA 5000h 105℃ T/R

Verical:
Cap Aluminum Lytic 100uF 6.3V 20% 6.3 X 5.8mm SMD 60mA 5000h 105C Automotive T/R
