UVY2G470MHD

Nichicon VY 系列Nichicon VY 系列铝电解电容器为微型尺寸的低阻抗高可靠性电容器，用于开关电源。 VY 系列非常可靠，具有长达 1000 小时的额定寿命，铝电解电容器还具有高波纹电流和温度范围。### 径向 105°C

VY 系列通用电解器

Nichicon VY 系列器为微型尺寸的低阻抗高可靠性电容器，用于开关电源。

### 特征与优势：

105°C 时具有 1000 小时的额定寿命

高波纹电流和温度范围

得捷:
CAP ALUM 47UF 20% 400V RADIAL

欧时:
Capacitor Electrolytic 47uF Radial

立创商城:
47uF ±20% 400V

艾睿:
Use this relatively high equivalent series resistance electrolytic UVY2G470MHD aluminum capacitor from Nichicon to generate high heat for a given current level. It can withstand a voltage of 400 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. It has a tolerance of 20%. Its leakage current is 852@1Min μA. This part has a lead diameter of 0.8 mm and a pitch of 7.5 mm. The UVY2G470MHD aluminum electrolytic capacitor has a radial termination style. Its capacitance value is 47uF. This product is 25 mm tall with a diameter of 16 mm.

Allied Electronics:
Capacitor; Aluminum Electrolytic; Cap 47uF 20% Radial 16X25 LS 7.5mm

安富利:
Cap Aluminum 47uF 400V 20% 16 X 25mm Radial 7.5mm 200mA 1000 hr 105°C Bulk

Chip1Stop:
Cap Aluminum Lytic 47uF 400V 20% 16 X 25mm Radial 7.5mm 200mA 1000h 105C Bulk

TME:
Capacitor: electrolytic; THT; 47uF; 400VDC; Ø16x25mm; Pitch:7.5mm
