UCC383T-ADJ

LDO（低压降）线性电压调节器，3A 至 7.5A，Texas Instruments### LDO（低压降）线性电压调节器，Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

可调 LDO（低压降）线性稳压器，3A 至 7.5A，Texas Instruments

得捷:
IC REG LINEAR POS ADJ 3A TO220-5

立创商城:
UCC383T-ADJ

德州仪器TI:
3-A, 9-V, ultra-low-dropout voltage regulator with reverse current protection from 0°C to 70°C

欧时:
### 可调 LDO（低压降）线性电压调节器，3A 至 7.5A，Texas Instruments### LDO（低压降）线性电压调节器，Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

贸泽:
LDO Voltage Regulators Low Power 3 Ampere

艾睿:
This LDO UCC383T-ADJ linear regulator from Texas Instruments gives you control over the voltage levels of your circuit. Its typical dropout voltage at current is 0.4@3A|0.2@1500mA|0.05@10mA V. It has an overall accuracy of ±2.5 %. This voltage regulation device&s;s single output can produce a current up to 3 A. With a small input voltage of 2.8 V and a max of 9 V, this will supply sufficient power to your circuit. With an adjustable output that has a voltage of 1.22 to 8.5 V, this is power management at its best. By operating at a load regulation of 5mV and line regulation of 3mV you can provide a constant voltage at your output. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This voltage regulation device has a minimum operating temperature of 0 °C and a maximum of 70 °C. The maximum dropout voltage is 0.6@3A|0.45@1500mA|0.15@10mA V. Its polarity is positive.

安富利:
LDO Regulator Pos 1.22V to 8.5V 3A 5-Pin5+Tab TO-220 Tube

Chip1Stop:
LDO Regulator Pos 1.22V to 8.5V 3A 5-Pin5+Tab TO-220 Tube

Verical:
LDO Regulator Pos 1.22V to 8.5V 3A 5-Pin5+Tab TO-220 Tube
