UC2707DWTRG4

双通道电源驱动器 DUAL CHANNEL POWER DRIVER

DESCRIPON

The UC1707 family of power drivers is made with a high-speed Schottky process to interface between low-level control functions and high-power switching devices - particularly power MOSFETs. These devices contain two independent channels, each of which can be activated by either a high

or low input logic level signal. Each output can source or sink up to 1.5A as long as power dissipation limits are not exceeded.

FEATURES

•Two independent Drivers

•1.5A Totem Pole Outputs

•Inverting and Non-Inverting Inputs

•40ns Rise and Fall into 1000pF

•High-Speed, Power MOSFET

Compatible

•Low Cross-Conduction Current Spike

•Analog Shutdown with Optional Latch

•Low Quiescent Current

•5V to 40V Operation

•Thermal Shutdown Protection

•16-Pin Dual-In-Line Package

•20-Pin PLCC and CLCC Package
