UST1C100MDD

10uF ±20% 16V Φ4mm 7mm

10µF 16V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C

立创商城:
10uF ±20% 16V

得捷:
CAP ALUM 10UF 20% 16V RADIAL

艾睿:
Using this electrolytic UST1C100MDD aluminum capacitor from Nichicon in your electronic circuit you&s;ll be able to generate high heat for a given current level due to its relatively high equivalent series resistance. It can withstand a voltage of 16 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. Its leakage current is 3@2Min μA. The UST1C100MDD aluminum electrolytic capacitor has a radial termination style. This part has a lead diameter of 0.45 mm and a pitch of 1.5 mm. It has a tolerance of 20%. This product is 7 mm tall with a diameter of 4 mm. Its capacitance value is 10uF.

安富利:
Cap Aluminum 10uF 16V 20% 4 X 7mm Radial 1.5mm 29mA 1000h 105°C Bulk

TME:
Capacitor: electrolytic; THT; 10uF; 16VDC; Ø4x7mm; Pitch:1.5mm

Verical:
Cap Aluminum Lytic 10uF 16V 20% 4 X 7mm Radial 1.5mm 29mA 1000h 105C Automotive Bulk
