UST1C101MDD

100uF ±20% 16V Φ8mm 7mm

100µF 16V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C

立创商城:
100uF ±20% 16V

得捷:
CAP ALUM 100UF 20% 16V RADIAL

贸泽:
Aluminum Electrolytic Capacitors - Leaded 16volts 100uF

艾睿:
Since the anode is made out of pure aluminum, you&s;ll be able to filter lower frequencies with ease using Nichicon&s;s electrolytic UST1C101MDD aluminum capacitor. It can withstand a voltage of 16 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. Its leakage current is 16@2Min μA. The UST1C101MDD aluminum electrolytic capacitor has a radial termination style. Its capacitance value is 100uF. This product is 7 mm tall with a diameter of 8 mm. It has a tolerance of 20%. This part has a lead diameter of 0.5 mm and a pitch of 3.5 mm.

Chip1Stop:
Cap Aluminum Lytic 100uF 16V 20% 8 X 7mm Radial 3.5mm 107mA 1000h 105ÂÂ℃ Bulk

TME:
Capacitor: electrolytic; THT; 100uF; 16VDC; Ø8x7mm; Pitch:3.5mm

Verical:
Cap Aluminum Lytic 100uF 16V 20% 8 X 7mm Radial 3.5mm 107mA 1000h 105C Automotive Bulk
