UPJ1A471MPD

470uF ±20% 10V 595mA100kHz595mA Φ8mm

470 µF 10 V 铝电解器 径向，Can - 105°C 时为 3000 小时

得捷:
CAP ALUM 470UF 20% 10V RADIAL

立创商城:
470uF ±20% 10V

艾睿:
Who knew generating high heat for a given current level would be this easy? Pick up this unique electrolytic UPJ1A471MPD aluminum capacitor from Nichicon for its relatively high ESR! It can withstand a voltage of 10 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. It has a tolerance of 20%. Its capacitance value is 470uF. This part has a lead diameter of 0.6 mm and a pitch of 3.5 mm. This product is 15 mm tall with a diameter of 8 mm. Its leakage current is 141@1Min μA. The UPJ1A471MPD aluminum electrolytic capacitor has a radial termination style.

安富利:
Cap Aluminum 470uF 10V 20% 8 X 15mm Radial 3.5mm 475mA 3000 hr 105°C Bulk
