UCY2G330MHD

33uF ±20% 400V Φ12.5mm 25mm

33 µF 400 V 铝电解器 径向，Can - 105°C 时为 12000 小时

欧时:
Electrolytic Capacitor

立创商城:
33uF ±20%

得捷:
CAP ALUM 33UF 20% 400V RADIAL

艾睿:
Who knew generating high heat for a given current level would be this easy? Pick up this unique electrolytic UCY2G330MHD aluminum capacitor from Nichicon for its relatively high ESR! It can withstand a voltage of 400 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. This product is 25 mm tall with a diameter of 12.5 mm. Its capacitance value is 33uF. It has a tolerance of 20%. This part has a lead diameter of 0.6 mm and a pitch of 5 mm. The UCY2G330MHD aluminum electrolytic capacitor has a radial termination style.

安富利:
Cap Aluminum 33uF 400V 20% 12.5 X 25mm Radial 5mm 385mA 10000 hr 105°C Bulk

TME:
Capacitor: electrolytic; THT; 33uF; 400VDC; Ø12.5x25mm; Pitch:5mm

Verical:
Cap Aluminum Lytic 33uF 400V 20% 12.5 X 25mm Radial 5mm 385mA 12000h 105C Automotive Bulk

Newark:
# NICHICON  UCY2G330MHD  Electrolytic Capacitor, Miniature, 33 µF, 400 V, CY Series, ± 20%, Radial Leaded, 12.5 mm
