SAMTEC UPS-04-07.0-01-L-V 板至板连接, UPS系列, 4 触点, 插座, 3.81 mm, 通孔安装, 1 排
4 位置 插座，母型刀片插口 焊接 0.150"（3.81mm） 通孔
欧时:
.150" PowerStrip/20 A Dual Blade Power S
得捷:
SOCKET DUAL LEAF 7POS 15A POWER
立创商城:
UPS-04-07.0-01-L-V
e络盟:
板至板连接, UPS系列, 4 触点, 插座, 3.81 mm, 通孔安装, 1 排
艾睿:
Are you looking for a solution to connecting a circuit to a power supply? Then use this power strip UPS-04-07.0-01-L-V power connector from Samtec for a secure connection! This SKT connector&s;s 4 contacts that are made out of beryllium copper and plated with gold over nickel. It has a socket type gender. This connector has a single port. It has a maximum voltage rating of 530 VDC|375VAC. It has a straight body orientation. UPS-04-07.0-01-L-V is housed in liquid crystal polymer. This device has a maximum current rating of 23 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This product is 22 mm long, 9.75 mm tall and 7 mm deep. This power connector has an operating temperature range of -55 °C to 125 °C. Its 24 terminals use the solder termination method.
