BiCMOS高级相移PWM控制器 BiCMOS ADVANCED PHASE-SHIFT PWM CONTROLLER
相移全桥 稳压器 正 输出 DC DC 切换控制器 IC 20-SOIC
得捷:
IC OFFLINE SW FULL-BRDG 20SOIC
立创商城:
UCC2895MDWREP
德州仪器TI:
Enhanced Product Bicmos Advanced Phase Shift Pwm Controller
贸泽:
Switching Controllers Mil Enh BiCMOS Adv Ph Shift PWM Cntrlr
艾睿:
Ideal for two part systems with different current needs, this UCC2895MDWREP current controller by Texas Instruments will exceed your needs. This current mode controller supports full-bridge topology. Its 4 PWM outputs produce a current of 100Max mA. Its switching regulator has a frequency of 1000 kHz. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This current mode controller has an operating temperature range of -55 °C to 125 °C. This device has a maximum of 17 V. This current mode controller&s;s maximum duty cycle is 100 %.
安富利:
Current Mode PWM Controller 100mA 20-Pin SOIC T/R
Chip1Stop:
Current Mode PWM Controller 100mA 20-Pin SOIC T/R
Verical:
Current Mode PWM Controller 100mA 1000kHz 20-Pin SOIC T/R
Newark:
PWM Controller, 10V-17.5V supply, 527kHz, 250mV/10mA out, SOIC-20
频率 527 kHz
电源电压DC 10.0V min
输出接口数 4
输出电压 250 mV
输出电流 10 mA
供电电流 6 mA
耗散功率 0.65 W
上升时间 20 ns
开关频率 1 MHz
拓扑结构 Full-Bridge
占空比 100 %
最大占空比 100 %
下降时间 20 ns
工作温度Max 125 ℃
工作温度Min -55 ℃
耗散功率Max 650 mW
电源电压 10V ~ 16.5V
电源电压Max 17.5 V
电源电压Min 10 V
安装方式 Surface Mount
引脚数 20
封装 SOIC-20
封装 SOIC-20
工作温度 -55℃ ~ 150℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
UCC2895MDWREP TI 德州仪器 | 当前型号 | 当前型号 |
V62/06614-01XE 德州仪器 | 类似代替 | UCC2895MDWREP和V62/06614-01XE的区别 |
