UM5-2424

MAT, UNIVERSAL SAFETY, 24IN X 24IN WITH 5METER 4 WIRE CABLE W QD

**Features:**

* Activation Force: 30 kg 66 Lb. Per ANSI/RIA 15.06-1999, ISO 13856-1:2001, ANSI B11.19-2003, and CSA Z432-04

* Conductive Plates: 24 Gauge Galvanealed Sheet Steel

* Contact Yield Strength in Excess of 20,000 Lb./Sq. In.; Fork Lift Traffic of 12,000 Lb.

* Mat Housing Cross Section: 13.5 mm 0.54 In.

* PVC Black or Yellow Covering Materials

* Single-Piece Molded Construction

* Mat Flammability Self Extinguishing, Meets UL94VO

* IP67 Rated

* Operating Temperature: –37 to +66°C –35 to +150°F

* Mat Cable: 18-Gauge, 4-Conductor, 16-Strand, 300 VAC

* Cable Length: Standard 5 m
