TDK VLS3015ET-3R3M 表面贴装功率电感器, VLS-E系列, 3.3 µH, ± 20%, 屏蔽, 0.112 ohm, 1.5 A
固定器
得捷:
FIXED IND 3.3UH 1.15A 112MOHM SM
立创商城:
3.3uH ±20% 1.15A 112mΩ
e络盟:
TDK VLS3015ET-3R3M 表面贴装功率电感器, 绕线铁氧体, VLS-E Series, 3.3 µH, 1.5 A, 1.3 A, 屏蔽, 0.112 ohm 新
艾睿:
Use this power VLS3015ET-3R3M surface mount inductor from TDK to make any circuit look clean and compact. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 105 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. It has an inductance of 3.3u H. This SMD inductor has a maximum DC current of 1.5Typ A with a maximum resistance of 112m Ohm. It has a tolerance of 20%. This product is 3.1 mm long, 1.5 mm tall and 3.1 mm deep. Its test frequency is 1M Hz. This device is made with wirewound technology.
安富利:
Ind Power Shielded Wirewound 3.3uH 20% 1MHz 1.5A 1212 T/R
Chip1Stop:
Inductor Power Shielded Wirewound 3.3uH 20% 1MHz Ferrite 1.5A 112mOhm DCR 1212 Blister T/R
Verical:
Inductor Power Shielded Wirewound 3.3uH 20% 1MHz Ferrite 1.5A 0.112Ohm DCR 1212 T/R
Newark:
# TDK VLS3015ET-3R3M INDUCTOR, SHIELDED, 3.3UH, 1.5A, 20% New
额定电流 1.15 A
容差 ±20 %
电感 3.3 µH
产品系列 VLS-E
电感公差 ±20 %
测试频率 1 MHz
电阻DC) ≤112 mΩ
工作温度Max 105 ℃
工作温度Min -40 ℃
精度 ±20 %
电阻DC Max 0.112 Ω
安装方式 Surface Mount
封装 1212
长度 3 mm
宽度 3 mm
高度 1.5 mm
封装 1212
工作温度 -40℃ ~ 105℃
产品生命周期 Not Recommended
包装方式 Tape & Reel TR
最小包装 2000
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
