VLCF4018T-3R3N1R2-2

TDK  VLCF4018T-3R3N1R2-2  表面贴装功率电感器, VLCF系列, 3.3 µH, ± 30%, 屏蔽, 0.079 ohm, 1.93 A

固定器

得捷:
FIXED IND 3.3UH 1.26A 79MOHM SMD

立创商城:
3.3uH ±30% 1.26A 79mΩ

欧时:
### VLCF4018 系列磁性屏蔽线绕扼流圈高磁屏蔽结构 通用便携式直流到直流变换器线路 测试频率 = 100 kHz ### TDK 非标准 SMT 电感器（扼流圈）

贸泽:
Fixed Inductors 3.3uH 1.2A 4x4x1.8mm

e络盟:
功率电感SMD, 绕线铁氧体, 3.3 µH, 1.93 A, 屏蔽, 1.26 A, VLCF Series, 4mm x 4mm x 1.8mm

艾睿:
Make any circuit look clean and compact using this power VLCF4018T-3R3N1R2-2 surface mount inductor from TDK. This SMD inductor has an operating temperature range of -40 °C to 105 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This SMD inductor has a maximum DC current of 1.93Typ A with a maximum resistance of 79m Ohm. It has an inductance of 3.3u H. This product is 4.1 mm long, 1.8 mm tall and 4.1 mm deep. This device utilizes wirewound technology. Its test frequency is 100K Hz.

安富利:
Ind Power Shielded Wirewound 3.3uH 30% 100KHz 1.93A T/R

Chip1Stop:
Ind Power Shielded Wirewound 3.3uH 30% 100KHz 1.93A T/R

Verical:
Inductor Power Shielded Wirewound 3.3uH 30% 100KHz Ferrite 1.93A 0.079Ohm DCR 1515 T/R

Newark:
# TDK  VLCF4018T-3R3N1R2-2  Surface Mount Power Inductor, VLCF Series, 3.3 H, 30%, Shielded, 0.079 ohm, 1.93 A

MASTER:
Inductor Power Shielded Wirewound 3.3uH 30% 100KHz Ferrite 1.93A 79mOhm DCR 1515 T/R

Online Components:
Inductor Power Shielded Wirewound 3.3uH 30% 100KHz Ferrite 1.93A 79mOhm DCR 1515 T/R

Electro Sonic:
Inductor Power Shielded Wirewound 3.3uH 30% 100KHz Ferrite 1.93A 79mOhm DCR 1515 T/R
