VLCF4020T-2R2N1R7

TDK  VLCF4020T-2R2N1R7  表面贴装功率电感器, 绕线铁氧体, VLCF Series, 2.2 µH, ± 30%, 屏蔽, 0.059 ohm, 1.72 A 新

固定器

欧时:
### VLCF4020 系列磁性屏蔽线绕扼流圈高磁屏蔽结构 通用便携式直流到直流变换器线路 测试频率 = 100 kHz ### TDK 非标准 SMT 电感器（扼流圈）

得捷:
FIXED IND 2.2UH 1.72A 59MOHM SMD

立创商城:
2.2uH ±30% 1.72A 59mΩ

贸泽:
Fixed Inductors 2.2uH 1.7A 4x4x2.0mm

e络盟:
功率电感SMD, 绕线铁氧体, 2.2 µH, 1.72 A, 屏蔽, 2.19 A, VLCF Series, 4mm x 4mm x 2mm

艾睿:
An ideal space-saving electronic component is this power VLCF4020T-2R2N1R7 surface mount inductor from TDK. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 105 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This product is 4.1 mm long, 2 mm tall and 4.1 mm deep. This device is made with wirewound technology. This SMD inductor has a maximum DC current of 2.19Typ A with a maximum resistance of 59m Ohm. It has an inductance of 2.2u H. Its test frequency is 100K Hz.

安富利:
Ind Power Shielded Wirewound 2.2uH 30% 100KHz 2.19A T/R

Chip1Stop:
Ind Power Shielded Wirewound 2.2uH 30% 100KHz Ferrite 2.19A T/R

Verical:
Inductor Power Shielded Wirewound 2.2uH 30% 100KHz Ferrite 2.19A 0.059Ohm DCR 1515 T/R

Newark:
# TDK  VLCF4020T-2R2N1R7  Surface Mount Power Inductor, VLCF Series, 2.2 µH, 1.72 A, 2.19 A, Shielded, 0.059 ohm

儒卓力:
**VLCF4020 2,2uH 1720mA 30% WWT **

MASTER:
Inductor Power Shielded Wirewound 2.2uH 30% 100KHz Ferrite 2.19A 59mOhm DCR 1515 T/R

Online Components:
Inductor Power Shielded Wirewound 2.2uH 30% 100KHz Ferrite 2.19A 59mOhm DCR 1515 T/R

Electro Sonic:
Inductor Power Shielded Wirewound 2.2uH 30% 100KHz Ferrite 2.19A 59mOhm DCR 1515 T/R

Win Source:
2.2μH Shielded Wirewound Inductor 1.72A 59 mOhm Max Nonstandard
