V5.5MLA0603H

LITTELFUSE  V5.5MLA0603H.  金属氧化物MOV压敏电阻

SMT 瞬态抑制器 - ML 系列

多层半导体陶瓷构造，提供双向钳位电压。 感应开关抑制或其它快速电气瞬态事件，使这些装置有利于实现成品的电磁兼容性。

适合于集成电路和晶体管的板载瞬态电压保护

在许多应用场合中可以代替较大的表面安装 TVS 齐纳管

得捷:
VARISTOR 8.2V 30A 0603

立创商城:
V5.5MLA0603H

欧时:
Littelfuse ML 系列 500pF 1A 17.5V 多层变阻器 V5.5MLA0603H, 0603 1608M封装, 1.6 x 0.8 x 1mm

e络盟:
TVS压敏电阻, MOV, ML系列, 4 V, 5.5 V, 17.5 V, 0603 [1608 公制], 多层压敏变阻器MLV

艾睿:
Have complete control of resistance in a voltage applied circuit by using this V5.5MLA0603H MOV developed by Littelfuse. This device&s;s clamping current is 1 A and clamping voltage is 17.5 V. Its maximum surge current is 30 A. This voltage dependent resistor has an operating temperature of -55 to 125 °C. Mount your voltage dependent resistor on a printed circuit board using surface mount technology to produce the most effective results. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This device is made with multilayer technology. This product is 1.6 mm long, 1 mm tall and 0.8 mm deep. Its capacitance value is 960pF. The maximum AC voltage rating is 4 VAC and the maximum DC voltage rating is 5.5 VDC. This varistor has a voltage of 9.3 V.

Allied Electronics:
ML Series Multilayer Varistor 500pF 1A; Clamping 17.5V; Varistor 9.3V 0603 Case

Chip1Stop:
Var MLV 4VAC/5.5VDC 30A 9.3V 0603 SMD Automotive T/R

TME:
Varistor: metal-oxide; SMD; 0603; 4VAC; 5.5VDC; 0.1J; 30A; 500pF

Verical:
Var MLV 4VAC/5.5VDC 30A 9.3V 0603 SMD T/R

Newark:
# LITTELFUSE  V5.5MLA0603H  TVS Varistor, MOV, 4 V, 5.5 V, ML Series, 17.5 V, 0603 [1608 Metric], Multilayer Varistor MLV

儒卓力:
**MLA 0603 DC=5,5V CL=17,5V 0,1J **

Win Source:
VARISTOR 8.2V 30A 0603
