MICRO SWITCH™ Miniature Basic Switches: V7 Series, Single Pole Normally Closed SPNC, 25A 277VAC, Pin Plunger, 225g [7.94 oz] Maximum Operating Force, 2,9mm [0.11in] Mounting Holes, -40℃ to 150℃ [-40 °F to 302 °F] Temperature Range, 6,35mm x 0,81mm [0.25in x 0.032in] Quick Connect Termination with Normally Closed Terminal Blade Formed Down 85°, UL, CSA
Snap action switches are highly sensitive switches that respond to very small movements and can rapidly change from one contact position to the other. V7 series Switches are mostly used in HVAC equipment, manually operated devices, valves and gaming equipment.
Snap Action Switch from Honeywell has a maximum pre-travel 1.19 mm and a minimum over-travel of 1.27 mm. The Honeywell Switch comes with a straight body orientation and an operating force of 0.59N.
Product Highlights
RoHS compliant
N.O./N.C. switch configuration
Maximum AC voltage rating of 277 V
Plastic plunger actuator
Single Pole Double Throw Circuitry
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
V7-3A17D8-000-3 Honeywell 霍尼韦尔 | 当前型号 | 当前型号 |
V-10-1C25-K 欧姆龙 | 功能相似 | V7-3A17D8-000-3和V-10-1C25-K的区别 |
V-16-1C25 欧姆龙 | 功能相似 | V7-3A17D8-000-3和V-16-1C25的区别 |
V-15-1C6 欧姆龙 | 功能相似 | V7-3A17D8-000-3和V-15-1C6的区别 |
