LA系列 330 VDC 250V RMS 650V 钳位 1200A 90pF 径向引线式压敏电阻
Have complete control of resistance in a voltage applied circuit by using this MOV developed by . This part has a pitch of 6 mm. This device"s clamping current is 10 A and clamping voltage is 650 V. Its maximum surge current is 1200 A. This voltage dependent resistor has an operating temperature of -55 to 85 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This varistor has a voltage of 429 V. This device is made with metal oxide technology. The maximum AC voltage rating is 250 VAC and the maximum DC voltage rating is 330 VDC. Its capacitance value is 90pF. This product is 15 mm tall and 5.6 mm deep with a diameter of 9 mm.
额定电压DC 330 V
额定电压AC 250 V
工作电压 429V max
额定电流 1200 A
电容 90 pF
电路数 1
钳位电压 650 V
工作温度Max 85 ℃
工作温度Min -55 ℃
额定电压DC Max 330 V
额定电压AC Max 250 V
安装方式 Through Hole
封装 Disc 7mm
宽度 5.6 mm
高度 15 mm
封装 Disc 7mm
工作温度 -55℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
V250LT4P Littelfuse 力特 | 当前型号 | 当前型号 |
V250LC4P 力特 | 完全替代 | V250LT4P和V250LC4P的区别 |
V250LT4 力特 | 完全替代 | V250LT4P和V250LT4的区别 |
V250LS4P 力特 | 类似代替 | V250LT4P和V250LS4P的区别 |
