VC060318A400RP

AVX  VC060318A400RP  TVS压敏电阻, TransGuard系列, 13 V, 18 V, 42 V, 0603 [1608 公制], 多层压敏变阻器MLV

表面安装瞬态抑制器 - TransGuard®

多层氧化锌陶瓷抑制器

铜包钢、镀层引线精加工

得捷:
VARISTOR 25.5V 30A 0603

立创商城:
18V 150pF

欧时:
AVX VC 系列 25.5V 30A 0.1J 42V钳位电压 陶瓷瞬态电压抑制器 VC060318A400RP, 18V最大直流额定电压

e络盟:
TVS压敏电阻, TransGuard系列, 13 V, 18 V, 42 V, 0603 [1608 公制], 多层压敏变阻器MLV

艾睿:
When different voltages are applied to this VC060318A400RP MOV from AVX will change resistance. Its maximum surge current is 30 A. This device&s;s clamping current is 1 A and clamping voltage is 42 V. This voltage dependent resistor has an operating temperature of -55 to 125 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. Mount your voltage dependent resistor on a printed circuit board using surface mount technology to produce the most effective results. The maximum AC voltage rating is 13 VAC and the maximum DC voltage rating is 18 VDC. Its capacitance value is 150pF. This product is 1.6 mm long, 0.9 mm tall and 0.8 mm deep. Its tolerance voltage is 10%. This device is made with multilayer technology. This varistor has a voltage of 25.5 V.

Allied Electronics:
VC Series 25.5V 30A 0.1J 42V Clamp 0603Ceramic Transient Voltage Suppressor

安富利:
Var MLV 13VAC/18VDC 30A 25.5V 0603 SMD T/R

Chip1Stop:
Var MLV 13VAC/18VDC 30A 25.5V 0603 SMD T/R

Verical:
Var MLV 13VAC/18VDC 30A 25.5V 0603 SMD T/R

Newark:
# AVX  VC060318A400RP  TVS Varistor, 13 V, 18 V, TransGuard Series, 42 V, 0603 [1608 Metric], Multilayer Varistor MLV

儒卓力:
**VC 0603 DC=18V CL=42V 0,1J 30A **

Win Source:
VARISTOR 25.5V 30A 0603
