VC120614D300RP

TransGuard®多层氧化锌陶瓷抑制器铜包钢、镀层引线精加工 ### 瞬态电压抑制器（ 陶瓷）

表面安装瞬态抑制器 - TransGuard®

多层氧化锌陶瓷抑制器

铜包钢、镀层引线精加工

欧时:
### 表面安装瞬态抑制器 - TransGuard®多层氧化锌陶瓷抑制器铜包钢、镀层引线精加工 ### 瞬态电压抑制器（ 陶瓷）

得捷:
VARISTOR 18.5V 150A 1206

贸泽:
压敏电阻 10VAC 14VDC 0.4J 1050pF 18.5 V 32V

艾睿:
Provide proper variable resistance to your circuit by using this VC120614D300RP MOV from AVX. This device&s;s clamping current is 1 A and clamping voltage is 32 V. Its maximum surge current is 150 A. This voltage dependent resistor has an operating temperature of -55 to 125 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. Mount your voltage dependent resistor on a printed circuit board using surface mount technology to produce the most effective results. This product is 3.2 mm long, 1.02 mm tall and 1.6 mm deep. Its tolerance voltage is 12%. This device utilizes multilayer technology. The maximum AC voltage rating is 10 VAC and the maximum DC voltage rating is 14 VDC. This varistor has a voltage of 18.5 V. Its capacitance value is 0.00105uF.

Allied Electronics:
VC Series 18.5V 150A 0.4J 32V Clamp 1206 Ceramic Transient Voltage Suppressor

安富利:
Var MLV 10VAC/14VDC 150A 18.5V 1206 SMD T/R

Chip1Stop:
Var MLV 10VAC 14VDC 150A 18.5V 1206 SMD T/R

Verical:
Var MLV 10VAC/14VDC 150A 18.5V 1206 SMD T/R

Newark:
# AVX  VC120614D300RP  TVS Varistor, 10 V, 14 V, TransGuard Series, 32 V, 1206 [3216 Metric], Multilayer Varistor MLV

儒卓力:
**VC 1206 DC=14V CL=32V 0,4J 150A **
