V0603MHS12NH

LITTELFUSE  V0603MHS12NH.  压敏变阻器, 18V, 55V, 0603

金属氧化物变阻器 - MHS 系列

MOV 的 Littelfuse MHS 系列是瞬态浪涌抑制器，可防范高速数据线和其他高频率应用中的 ESD 和 EFT。MHS 系列电容较低，可以用于模拟或数字电路，不会减少或扭曲所需的信号或数据。MHS 系列小巧紧凑，特别适用于高密度印刷电路板，保护集成电路和其他敏感组件。

得捷:
VARISTOR 55V 0603

立创商城:
V0603MHS12NH

欧时:
Littelfuse MHS 系列 16pF 1A 55V 金属氧化物压敏电阻 V0603MHS12NH, 0603 1608M封装, 1.6 x 0.8 x 1mm

e络盟:
压敏变阻器, 18V, 55V, 0603

艾睿:
Never worry about improper resistance being seen by your components with this V0603MHS12NH MOV from Littelfuse, it will change depending on voltages. This device&s;s clamping current is 1 A and clamping voltage is 55 V. This voltage dependent resistor has an operating temperature of -55 to 125 °C. Mount your voltage dependent resistor on a printed circuit board using surface mount technology to produce the most effective results. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This product is 1.6 mm long, 0.9 mm tall and 0.8 mm deep. The maximum DC voltage rating is 18 VDC. This device is made with multilayer technology. Its capacitance value is 12pF.

Allied Electronics:
MHS Series Metal Oxide Varistor 16pF 1A, Clamping 55V 0603, 1608 Case

Chip1Stop:
Var MLV 18VDC 0603 SMD T/R

Verical:
Var MLV 14VAC/18VDC 0603 SMD T/R

Newark:
# LITTELFUSE  V0603MHS12NH  TVS Varistor, 18 V, MHS Series, 55 V, 0603 [1608 Metric], ESD Protector

儒卓力:
**MHS 0603 DC=18V CL=55V **

Win Source:
VARISTOR 55V 0603
